Rocking levers support unit
1
2
3
4
5
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1
Camshaft complete of bearing he vesp
SP1A020424
£207,83 Unit Price incl. VAT
2
Culbuteur axe
B017113
£0,59 Unit Price incl. VAT
3
Couronne distribution
B019040
£19,09 Unit Price incl. VAT
4
Culbuteur côté admission complet
1A018611
£28,49 Unit Price incl. VAT
5
Vis rég. soupapes
B017323
£0,38 Unit Price incl. VAT
6
Ecrou réglage culbuteur
B017431
£0,19 Unit Price incl. VAT
7
Culbuteur côté échappement complet
1A018664
£28,49 Unit Price incl. VAT
8
Tôle d'arrêt de masse de décompression
1A008397
£1,57 Unit Price incl. VAT
9
Vis M5x14
B018718
£0,14 Unit Price incl. VAT
10
Tôle d'arrêt d'arbre à cames
1A018855
£3,31 Unit Price incl. VAT
11
Vis M6x18
B018946
£0,14 Unit Price incl. VAT
12
Guarnizione cilindro/tendicatena
847928
£3,24 Unit Price incl. VAT
13
Vis hexagonale bridée M6x16
1F000110
£2,32 Unit Price incl. VAT
14
Support tendeur de chaîne
1A019253
£35,66 Unit Price incl. VAT
15
Tge tendeur de chaîne
1A018706
£8,92 Unit Price incl. VAT
16
Vis spéciale
B014237
£5,04 Unit Price incl. VAT
17
Joint torique 20.35x1.78
B017406
Not Available
18
Patin fixe
1A018705
£7,14 Unit Price incl. VAT
19
Chaîne de distribution
1A019143
£11,27 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
