1
Engine displacement
250
2
Model
LEONARDO
3
Year
2001
4
Trim
Leonardo (engine Yamaha)
5
Parts Catalog
Transmission
6
Parts Diagram
Parts Catalog
Starter motor
by
Clutch
Transmission
1
2
3
3
4
4
5
6
7
8
9
10
11
12
13
14
15
1
Intermediate gear
AP8106683
Not Available
2
Gear
AP8122502
Not Available
3
Washer
AP8122651
Not Available
4
Roller bearing
AP8125826
Not Available
5
Drive shaft
AP8106682
Not Available
6
Gear
AP8122497
Not Available
7
Circlip
AP8122443
Not Available
8
Washer
AP8122648
Not Available
9
Bearing 6303-2RS 17x47x14
AP8122428
Not Available
10
Bearing
AP8125825
Not Available
11
Oil seal
AP8122536
Not Available
12
Bearing 6302-2RS 15x42x13
AP8122427
£29,15 Unit Price incl. VAT
13
Drive shaft
AP8122501
Not Available
14
Bearing
AP8125823
Not Available
15
Oil seal
AP8122537
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
