Throttle body - Injector - Union pipe

TRANSMISSION ASSEMBLY FOR APRILIA SRV 4T 8V E3 2012

Crankcase

Item numbers

COMPLETE CARDAN JOINT
COMPLETE CARDING AXLE

876490

£266,60

Unit Price Incl. Tax

WASHER
FLAT WASHER

874981

£9,77

Unit Price Incl. Tax

SLIDING BLOCK
SLIDER

8753764

Contact

JOINT COVER WITH I.P.
JOINT COVER

601550

Contact

OIL LEVEL GAUGE
OIL LEVEL INDICATOR

485693

£16,10

Unit Price Incl. Tax

SEAL RING (O-RING)
GASKET RING

601552

Contact

HEXAGON SOCKET BUTTON HEAD SCREW
HEX SOCKET SCREW

873433

£1,32

Unit Price Incl. Tax

SCREW (CYLINDER HEAD)
SCREW M8X10

846609

£1,21

Unit Price Incl. Tax

WASHER
WASHER 8.2X12X1

485703

£0,96

Unit Price Incl. Tax

CARDAN JOINT SUPPORT WITH IP.
CARDING SUPPORT WITH I.P.

649415

£90,62

Unit Price Incl. Tax

AUTO-BLOCK HEXAGON SOKET BUTTON SCREW
HEX SOCKET SCREW

650901

£1,17

Unit Price Incl. Tax

PLAIN WASHER
WASHER

650084

£17,56

Unit Price Incl. Tax

BALL BEARING
RADIAL BEARING

82925R

Contact

O-RING GASCKET
GASKET

846607

Contact

SPACER

649427

Contact

SEAL RING
GASKET RING 58-72-8

846606

£31,98

Unit Price Incl. Tax

BALL BEARING
RADIAL BEARING 50X72X12

82924R

£117,26

Unit Price Incl. Tax

SPROCKET
PINION 5/8" X 5/16"

649484

£111,60

Unit Price Incl. Tax

BUSHING DRIVING PULLEY
BUSHING

876014

£290,41

Unit Price Incl. Tax

OIL SEAL CASING ASSY
COMPLETE OIL SEAL HOOD

649928

£66,99

Unit Price Incl. Tax

OIL SEAL CASING FIXING RING LOCKED
HOOD FIXING RING

649474

£43,85

Unit Price Incl. Tax

HEXAG. HEAD SCREW

847421

1A000424

£6,99

Unit Price Incl. Tax

CLAMP
HOSE CLAMP M4

650153

£19,02

Unit Price Incl. Tax

RING

650132

£23,88

Unit Price Incl. Tax

SOCKET HEAD SCREW
SPECIAL CAP SCREW

564632

£1,17

Unit Price Incl. Tax

CURVED SPRING WASHER
WASHER

006970

Contact

NOZZLE FOR CARTER
PIN 11, 8X10

825597

£2,35

Unit Price Incl. Tax

CHAIN CONTEINMENT PLATE WHIT I.P
PINION PROTECTION

649826

£29,63

Unit Price Incl. Tax

SCREW

030062

Contact

WAVED SPRING WASHER
SPRING WASHER 12X6, 4X0, 5

006976

Contact

CHAIN
CHAIN 137/525

649481

£166,15

Unit Price Incl. Tax

CHAIN TIGHTENER WHEEL ASSY
CHAIN TIGHTENER WHEEL ASSY

649823

6498236

£33,92

Unit Price Incl. Tax

RULLO CATENA
BLACK CHAIN GUIDE ROLLER

AP8161074

£13,28

Unit Price Incl. Tax

CUSCINETTO RULLO CATENA
BEARING

AP8110117

£8,71

Unit Price Incl. Tax

SPACER

AP8161076

£5,14

Unit Price Incl. Tax

SCREW WITH CYLINDRICAL HEAD
HEX SOCKET SCREW

826298

£1,19

Unit Price Incl. Tax

WASHER

316144

£0,89

Unit Price Incl. Tax

RING
SNAP RING

650103

£23,56

Unit Price Incl. Tax

PLATE WHEELS
CHAIN RING 5/16

651095

Contact

FLANGED BOLT WITH HEX. (HEAD WITH RECESS
SCREW W/ FLANGE

651295

£1,23

Unit Price Incl. Tax

RUBBER BUSHING
SPRING DRIVE RUBBER

650743

£19,77

Unit Price Incl. Tax

COMPLETE SPRING DRIVE
COMPLETE FLEXIBLE COUPLING UNIT

650745

£650,03

Unit Price Incl. Tax

NUT M8
NUT

195483

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
