Parts catalogue

Parts diagram

Transmission assembly

CRANKCASE FOR APRILIA SRV 4T 8V E3 2012

Crankcase cover - Crankcase cooling

Item numbers
Crankcase Aprilia APRILIA-SCOOTER 850 SRV 2012 SRV 4T 8V E3
1
1
2
3
4
5
6
7
8
8
8
9
9
10
10
11
12
13
14
15
16
17
18
18
19
19
20
20
20
20
21
22
23
24
25
26
27
28
29
30
31
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
45
46
47
48
49
50
51
52
1
CRANKCASE, ASSY
COMPLETE CRANKCASE 1ST CAT.

B0173160001  

Unit Price Incl. Tax

1
CRANKCASE, ASSY
2ND CAT. COMPLETE CRANKCASE

B0173160002  

Unit Price Incl. Tax

2
RING
SNAP RING

006662  

Contact
3
RADIAL BEARING
BEARING

82926R  

Unit Price Incl. Tax

4
SEAL RING
GASKET RING

825023  

Unit Price Incl. Tax

5
DEEP GROOVE BALL BEARING
RADIAL BALL BEARING 20X47X14

833701  

Contact
6
RADIAL BEARING
BALL BEARING

845439  

Contact
7
SEAL RING
GASKET RING 50-68

845443  

Unit Price Incl. Tax

8
ANTI-TAPPING DOWEL
LOCATING DOWEL

484993  

Unit Price Incl. Tax

9
BUSH

623857  

Unit Price Incl. Tax

10
NEEDLE BEARING
ROLLER CAGE

845684  

Unit Price Incl. Tax

11
AIR DEFLECTOR
FUEL BAFFLE

875442  

Unit Price Incl. Tax

12
PACKING
GASKET

831393  

Unit Price Incl. Tax

13
SEAL RING
GASKET RING 35X50X7

832987  

Unit Price Incl. Tax

14
OIL FILTER UNION

832985  

Unit Price Incl. Tax

15
PIN D.9, 5 H=15
REFERENCE PLUG (D9.5, H=15)

239388  

B015956

Unit Price Incl. Tax

16
LOCATING DOWEL
REFERENCE DOWEL

478115  

B015957

Unit Price Incl. Tax

17
SIZING NOZZLE WITH I.P.
NOZZLE

830666  

Unit Price Incl. Tax

18
PLUG M12X1, 5X11
TAPER THREADED PLUG

411311  

B015433

Unit Price Incl. Tax

19
NOZZLE FOR CARTER
PIN 11, 8X10

825597  

Unit Price Incl. Tax

20
STUD BOLT
CYLINDER STUD

877281  

1A003631R

Unit Price Incl. Tax

21
PUMP SHAFT WATER
WATER PUMP SHAFT ASSY.

872025  

Unit Price Incl. Tax

22
FLAT WASHER
SHIM WASHER

974290  

Unit Price Incl. Tax

23
AIR DEFLECTOR

874451  

Unit Price Incl. Tax

24
WASHER 10, 5X17X1, 5

AP9150472  

Unit Price Incl. Tax

25
SEAL RING

873934  

1A018564

Unit Price Incl. Tax

26
WATER PUMP SEAL RING
GASKET RING

82991R  

Unit Price Incl. Tax

27
WATER PUMP ROTOR
IMPELLER

833054  

Unit Price Incl. Tax

28
REED CASE BRACKET
REED VALVE SUPPORT

82778R  

Unit Price Incl. Tax

29
INTERNAL AIRBOX COVER
COVER SAS

827209  

Unit Price Incl. Tax

30
CYLINDER HEAD SCREW
SCREW

873102  

Unit Price Incl. Tax

31
NOZZLE FOR ENGINE SIDECASE
NOZZLE

825649  

Unit Price Incl. Tax

32
ENGINE HALF-CRANKCASE GASKET
HALF CRANKCASE GASKET MM 0, 3

872625  

Unit Price Incl. Tax

33
BRACKET WITH SILENT-BLOCK
EXHAUST PIPE SUPPORT CLAMP

875518  

Unit Price Incl. Tax

34
FLANGED HEXAG. HEAD SCREW
SCREW W/ FLANGE M6X90

874746  

Unit Price Incl. Tax

35
FLANGED HEXAG. HEAD SCREW
SCREW W/ FLANGE M8X60

874747  

Unit Price Incl. Tax

36
FLANGED HEXAGONAL HEAD SCREW
SCREW W/ FLANGE M8X85

874748  

Unit Price Incl. Tax

37
WASHER 8.2X12X1
WASHER

106009  

485703

Unit Price Incl. Tax

38
AIR DEFLECTOR

832981  

Contact
39
VIS TCIC M5X10
CROSS SLOTTED SCREW WITH CYLINDER HEAD

018575  

1A003111

Unit Price Incl. Tax

40
STEEL SHEET OIL BAFFLE
PLATE

843317  

Unit Price Incl. Tax

41
VIS TCIC M5X10
CROSS SLOTTED SCREW WITH CYLINDER HEAD

018575  

1A003111

Unit Price Incl. Tax

42
AIR GRATING
GRID

834345  

Unit Price Incl. Tax

43
VIS TCIC M5X10
CROSS SLOTTED SCREW WITH CYLINDER HEAD

018575  

1A003111

Unit Price Incl. Tax

44
PHASE/REVOLUTION SENSOR
PHASE SENSOR

832963  

8329635

Unit Price Incl. Tax

45
WIRING HARNESS FOR SENSOR
JOINT.P.

584838  

Contact
45
WIRING HARNESS FOR PHONIC WHEEL SENSOR
JOINT.P.

643331  

Unit Price Incl. Tax

46
SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541  

B016777

Unit Price Incl. Tax

47
OIL UNLOAD PLUG
OIL DRAIN PLUG COMPLETE

82929R  

B015860

Unit Price Incl. Tax

48
SEAL RING (O-RING)
O-RING

843186  

Unit Price Incl. Tax

49
OIL PUMP PAD
CHAIN GUIDE PLATE

831335  

Unit Price Incl. Tax

50
CYLINDER HEAD SCREW
SCREW

873102  

Unit Price Incl. Tax

51
MINIMUM OIL PRESSURE SENSOR
MINIMUM PRESSURE OIL SWITCH

641541  

Contact
52
GASKET RING
O-RING

430044  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
