ELECTRICAL SYSTEM FOR APRILIA SX LIMITED EDITION 2017

Exhaust unit

Item numbers

MAIN WIRING HARNESS

867477

£389,26

Unit Price Incl. Tax

FUSE
FUSE 7, 5A

00H01001911

£14,05

Unit Price Incl. Tax

BLACK CABLE TIE
HOSE CLAMP

00D00900531

£1,44

Unit Price Incl. Tax

TIMER CHECK INDICATOR
FLASHER UNIT

00H05700481

£38,36

Unit Price Incl. Tax

FRONT HANDLEBARS COVER
FRONT HEADLIGHT COV.

2B000016000XN4

£129,51

Unit Price Incl. Tax

HEADLIGHT

855038

£134,13

Unit Price Incl. Tax

SCREW 4M70X50
SCREW

00012045000

Contact

SPRING

00H02304501

Contact

HEXAGON COCKET SCREWS M6X20 Z.N.
HEX SOCKET SCREW M6X20

AP8152137

£2,23

Unit Price Incl. Tax

LAMP 12V-35/35W
LAMP 12 V 35/35 W

00H01000131

219528

£8,93

Unit Price Incl. Tax

LAMP 12V/35/35W HS1 (HALOGEN)
LAMP HS1 35+35W 12V

231215

£20,46

Unit Price Incl. Tax

INDICATORE DIREZ.ANT.SX
LH FRONT/RH REAR TURN INDIC.

AP8127784

£50,61

Unit Price Incl. Tax

TAIL LIGHT ASSY
TAILLIGHT

00H01009321

£97,89

Unit Price Incl. Tax

HEADLIGHT STOP
GASKET

00H05700101

£7,61

Unit Price Incl. Tax

WASHER
WASHER 6, 4X15X1

AP8152181

£0,23

Unit Price Incl. Tax

HEADLIGHT CUSING SUPPORT
MAINTENANCE

00H01502741

£10,73

Unit Price Incl. Tax

ROUNDHEAD PHILIPS SCREW 5M80X1
SCREW 5M80X12

00012051200

Contact

WASHER

847181

£19,50

Unit Price Incl. Tax

HEX NUT WITH FLANGE
NUT 5M80

00026005000

Contact

CLAMP
HOSE CLAMP

00H04603841

£13,62

Unit Price Incl. Tax

LAMP RY10W 12V

AP8127489

£5,91

Unit Price Incl. Tax

CABLE PROTECTOR
GROMMET

00008915020

Contact

BUSHING
RING NUT

00D01500471

£7,65

Unit Price Incl. Tax

WASHER
WASHER D6

00D01200171

£1,21

Unit Price Incl. Tax

SELF-LOCKING NUT M6
NUT M6100

00000023060

Contact

VOLTAGE REGULATOR

898891

£89,11

Unit Price Incl. Tax

SCREW
SCREW

00D05900081

00D05910081

£1,21

Unit Price Incl. Tax

HEX SOCKET SCREW M6X20

AP8150044

£1,21

Unit Price Incl. Tax

SPRING PLATE M6
SPRING PLATE (M6)

00D01501371

254485

£1,57

Unit Price Incl. Tax

HORN ASSEMBLY
HORN

00H01005311

£46,13

Unit Price Incl. Tax

SCREW M6X12
SCREW 6MX100X12

00012061200

Contact

BUSH

AP8121991

£3,44

Unit Price Incl. Tax

LIGHTS WIRING
TOWN LIGHTS SWITCH WIRING

856610

£43,05

Unit Price Incl. Tax

BULB HOLDER SPRING
SPRING

00003710120

Contact

GROMMET
RUBBER SPACER

00H05701061

£3,13

Unit Price Incl. Tax

BLACK CABLE TIE
HOSE CLAMP 290X4, 8

00F00900531

£4,91

Unit Price Incl. Tax

BLACK CABLE TIE
HOSE CLAMP

00D00900531

£1,44

Unit Price Incl. Tax

WIRING HARNESS CONNECTOR
GUARD

00H02300961

£16,58

Unit Price Incl. Tax

SCREW

00011061300

Contact

TURN SIGNAL LAMP DX
RH FRONT/LH REAR TURN INDIC.

AP8127783

£50,61

Unit Price Incl. Tax

PLACA SOPTE.LUZ MATRICULA DRD PRO SZA.
NUMBER PLATE HOLDER

861313

£14,50

Unit Price Incl. Tax

LIGHT OF REGISTER BIKE
COMPLETE LICENSE PLATE LIGHT

00H05700471

£81,80

Unit Price Incl. Tax

ELECTRICAL EQUIPMENT
PLATE LIGHT WIRING

861315

£35,43

Unit Price Incl. Tax

BULB
LAMP 12V-5W

00H01003131

£2,01

Unit Price Incl. Tax

ALLEN SCREW M5X16 - 8.8 DA UNI5931
HEX SOCKET SCREW

AP8150280

£4,97

Unit Price Incl. Tax

WASHER 5, 5X15X1, 2 ZB UNI6593 R40
WASHER 5, 5X15X1, 6

AP8150248

£0,94

Unit Price Incl. Tax

SELF-LOCKING NUT M5
SELF-LOCKING NUT M5*

AP8150311

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
