BODY FOR APRILIA SX LIMITED EDITION 2017

Frame

Item numbers

FRONT MUDGUARD

2B000015000W0B

£48,33

Unit Price Incl. Tax

FRONT MUDGUARD

2B000015000W0N

£48,33

Unit Price Incl. Tax

HEXAGONAL SOCKET SCREW M6X16
SCREW W/ FLANGE M6X16

AP8152246

£3,85

Unit Price Incl. Tax

SCREW M6X12
SCREW 6MX100X12

00012061200

Contact

R.H. BODY SIDE
RH FRONT SIDE PANEL

2B000013000W0N

£53,11

Unit Price Incl. Tax

R.H. BODY SIDE
LH FRONT SIDE PANEL

2B000014000W0N

£53,11

Unit Price Incl. Tax

COUVRE-STR.SELLE D, NOIR
RH SADDLE SUP COVER

86108200W0N

£14,25

Unit Price Incl. Tax

LH SADDLE SUP COV., BLACK
LH SADDLE SUP COVER

86108300W0N

£14,25

Unit Price Incl. Tax

SPRING PLATE M6

254485

£1,57

Unit Price Incl. Tax

HEXAGONAL SOCKET SCREW M6X16
SCREW W/ FLANGE M6X16

AP8152246

£3,85

Unit Price Incl. Tax

SCREWS FOR PLASTIC INOX -SWP 3, 9X7, 5
SELF-TAPPING SCREW *

AP8150420

£1,80

Unit Price Incl. Tax

NUMBER PLATE HOLDER

894118

£18,63

Unit Price Incl. Tax

REAR REFLECTOR, RED

00K05110651

AP8224164

£10,82

Unit Price Incl. Tax

REAR MUDGUARD

00H00705121

£36,69

Unit Price Incl. Tax

GEAR MUDFLAT
REAR FAIRING

2B000012000W0B

£217,35

Unit Price Incl. Tax

GEAR MUDFLAT
REAR FAIRING

2B000012000W0N

£217,35

Unit Price Incl. Tax

REFLECTOR

00H01802081

£15,66

Unit Price Incl. Tax

MACHINED FLAT WASHER D6 DIN-12
WASHER D6 DIN125 AZNB

00402060001

Contact

WASHER 5, 5X15X1, 2 DA UNI 6593 R50
WASHER 5, 5X15X1, 6*

AP8150013

£1,53

Unit Price Incl. Tax

LOW SELF-LOCKING NUT M4*
NUT M4

AP8150204

£1,80

Unit Price Incl. Tax

CABLE GUIAE
GUARD

00H02201591

£1,93

Unit Price Incl. Tax

GROMMET
RUBBER SPACER

00D01500021

£8,98

Unit Price Incl. Tax

WASHER
WASHER

00000031050

847226

£0,49

Unit Price Incl. Tax

SELF-TAPPING SCREW
SELF-TAP SCREW 3, 9X14

AP8150413

£1,53

Unit Price Incl. Tax

ALLEN SCREW M5X15
SCREW

00002052051

Contact

CLIP M5

AP8102375

£2,10

Unit Price Incl. Tax

FLANGE D8 D8
BRIDA PASACABLES D8 ISC NG

00H01501811

864454

£2,22

Unit Price Incl. Tax

SELF-LOCKING NUT M6

AP8152299

£1,80

Unit Price Incl. Tax

HOSE CLAMP D.8
BLACK HOSE D8

AP8101890

£2,68

Unit Price Incl. Tax

HEX SOCKET SCREW M6X25
HEX SOCKET SCREW M6X25

00002062511

AP8150165

£0,85

Unit Price Incl. Tax

SELF-LOCKING NUT M6
NUT M6100

00000023060

Contact

WASHER 4, 3X9X0, 8 DA ISO 7089 R40
WASHER 4, 3X9X0, 8

AP8150158

£1,21

Unit Price Incl. Tax

PUSH ON FASTENERS FOR 5MM SHAFT
WASHER FOR SHAFTS D5

AP8150450

£2,10

Unit Price Incl. Tax

WASHER 6, 4X12, 5
WASHER 6, 4X12, 5*

AP8150178

£1,21

Unit Price Incl. Tax

LATERAL PROTECTION
RH REAR PANEL

2B000010000W0B

£41,43

Unit Price Incl. Tax

LATERAL PROTECTION
RH REAR PANEL

2B000010000W0N

£41,43

Unit Price Incl. Tax

LATERAL PROTECTION
LH REAR PANEL

2B000011000W0B

Contact

LATERAL PROTECTION
LH REAR PANEL

2B000011000W0N

£41,43

Unit Price Incl. Tax

WASHER
WASHER D6

00D01200171

£1,21

Unit Price Incl. Tax

BUSH
RING NUT

862449

£4,97

Unit Price Incl. Tax

TENSION
TIE ROD

89411900XN4

£22,04

Unit Price Incl. Tax

SCREW W/ FLANGE M5X16

AP8152298

£3,32

Unit Price Incl. Tax

HEXAGON COCKET SCREWS M5X9
SCREW W/ FLANGE M5X9

AP8152339

£1,86

Unit Price Incl. Tax

BUSHING
BUSH

AP8121032

£3,71

Unit Price Incl. Tax

RUBBER
RUBBER SPACER

AP8120405

£5,29

Unit Price Incl. Tax

WASHER

00H03800722

£1,49

Unit Price Incl. Tax

SCREW
PHILLIPS SCREW, SWP M5X20

AP8152329

£1,71

Unit Price Incl. Tax

COVER
WIRING COVER

894122

£14,28

Unit Price Incl. Tax

BUSHING
BUSH

AP8121032

£3,71

Unit Price Incl. Tax

SPACER

840509

£4,91

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
