Parts Catalog
Exhaust unit
6
Parts Diagram
Parts Catalog
Swing arm
by
Handlebar - Controls
Exhaust unit
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
22
23
24
25
26
27
28
29
30
31
32
33
34
35
1
Silencer
AP8119300
Not Available
1
Silencer
AP8119319
Not Available
1
Silencer
AP8119272
Not Available
2
Silencer
AP8119242
Not Available
3
Exhaust pipe prot., black
AP8119198
Not Available
4
Exhaust pipe leading pipe
AP8119309
Not Available
4
Exhaust pipe leading pipe
AP8119241
Not Available
5
O-ring 3112
AP8120635
Not Available
6
O-ring 3187
AP8120636
Not Available
7
Filter housing base
AP8102099
Not Available
7
Filter housing base
AP8131563
Not Available
8
Filter holder
AP8101948
Not Available
9
Filter case cover, black
AP8102100
Not Available
10
Carburettor-air box hose
AP8120630
Not Available
11
Water cooler
AP8102241
Not Available
11
Water cooler
AP8102132
Not Available
12
Rad cap no vent
AP8101912
£17,23 Unit Price incl. VAT
13
Cooler-pump pipe
AP8101960
Not Available
13
Cooler-pump pipe
AP8120775
Not Available
14
Water cooler-head tube
AP8101959
Not Available
14
Water cooler-head tube
AP8120774
Not Available
15
T bush *
AP8121725
£1,88 Unit Price incl. VAT
16
Rubber spacer *
AP8120223
£2,74 Unit Price incl. VAT
17
Electric fan assy.
AP8112556
Not Available
17
Electric fan
AP8112864
Not Available
18
Thermal switch
AP8112559
Not Available
19
Fan support
AP8138103
Not Available
20
Sprocket cover, black
AP8106069
Not Available
20
Sprocket cover, black
AP8120773
Not Available
22
Carburettor PHBH 26 CS-282 CC
AP8106212
Not Available
22
Carburettor PHBH 26CS-282CC
AP8106151
Not Available
22
Carburettor 242 CC-PHBH 26 CS
AP8106082
Not Available
23
Gear lever
AP8106114
Not Available
24
Kick-start lever
AP8135325
Not Available
25
Expansion tank
AP8104036
Not Available
25
Expansion tank
AP8102242
Not Available
26
Silent-block
AP8120335
Not Available
27
Filter case guard plate
AP8131643
Not Available
27
Filter case guard plate
AP8102037
Not Available
28
Spring
AP8121781
Not Available
29
Plate
AP8134215
Not Available
30
2-way union
AP8101944
£5,48 Unit Price incl. VAT
31
Rubber spacer *
AP8120598
Not Available
32
Cap
AP8112577
Not Available
33
Clip
AP8102284
Not Available
34
Pipe cover
AP8138047
Not Available
34
Pipe cover
AP8131647
Not Available
35
Hose
AP8120681
Not Available

Find the detailed Exhaust unit APRILIA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original APRILIA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
