Cylinder - Head - Piston N>S

CYLINDER - HEAD - PISTON T FOR APRILIA PEGASO 1994

Body

Item numbers
Cylinder - Head - Piston T Aprilia APRILIA-MOTORCYCLES 650 PEGASO 1994 PEGASO
1
8
9
10
11
12
13
14
15
16
17
18
19
19
20
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
50
50
50
51
1
AP0223529
CYLINDER HEAD

AP0223529  

Contact
8
BREAK WASHER A6

AP0945751  

Contact
9
HEX SOCKET SCREW M6X25

AP0840861  

Contact
10
GASKET

AP0250025  

Contact
11
ANGULAR UNION

AP0222226  

Contact
12
TEMP. SENSOR

AP0222420  

Contact
13
BREAK WASHER A5

AP0945750  

Contact
14
SCREW M5X20
SCREW

AP0240182  

Contact
15
ANGULAR UNION
ANGULAR UNION

AP0922245  

Contact
16
STUD BOLT M8X58

AP0240362  

Contact
17
GASKET
GASKET

AP0230602  

AP0230604

Unit Price Incl. Tax

18
RUBBER SPACER

AP0247955  

Contact
19
NUT M10
NUT

AP0242851  

Contact
20
HEX SOCKET SCREW M6X30
HEX SOCKET SCREW

AP0840882  

Contact
22
PIN 3X9, 8

AP0232990  

Contact
23
BUSH

AP0236100  

Contact
24
SPRING

AP0239310  

Contact
25
CHAIN TENSIONER HOUSING

AP0236081  

Contact
26
HEX SOCKET SCREW M6X22
HEX SOCKET SCREW

AP0840402  

Contact
27
ADJUSTER SCREW INT. M18X2, 5

AP0229330  

Contact
28
SPRING

AP0239180  

Contact
29
ADJUSTER SCREW EXT.

AP0229320  

Contact
30
NUT M24X1

AP0242840  

Contact
31
HOSE CLAMP D16, 5

AP0251010  

Contact
32
HOSE CLAMP D18
HOSE CLAMP D18

AP0260141  

AP0251170

Unit Price Incl. Tax

33
HOSE CLAMP

AP0251920  

Contact
34
RUBBER SPACER

AP0260310  

Contact
35
O-RING 23, 3X2, 4

AP0430782  

Contact
36
PLUG M24X1
COVER M24X1

AP0241370  

Contact
37
COVER

AP0260961  

Contact
38
VALVES COVER

AP0210674  

Contact
39
UPPER CHAIN GUIDE PLATE

AP0236130  

Unit Price Incl. Tax

40
PLUG M16X1, 5 REF. ROTAX 240234
PLUG M16X1, 5 REF. ROTAX 240234

AP0240232  

Contact
41
GASKET RING 16X22

AP0430622  

Contact
42
O-RING

AP0230540  

Contact
43
WASHER 6, 4
WASHER 6, 4

AP0244217  

Contact
44
HEX SCREW

AP0941122  

Contact
45
INTAKE VALVE GUIDE

AP0253591  

Contact
46
INTAKE VALVE GUIDE

AP0253596  

Contact
47
EXHAUST VALVE GUIDE

AP0253581  

Contact
48
CIRCLIP 11X1

AP0245710  

Contact
49
MOLYKOTE G-N 50GR.

AP0297433  

Contact
50
LOCTITE (ORANGE) 574

AP0899784  

Contact
51
SILASTIC 732RTV 100GR.

AP0297385  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Aprilia PEGASO 1994
