HEAD - CYLINDER - PISTON FOR APRILIA MINI RX ENTRY 2003
Item numbers
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
CYLINDER WITH PISTON
AP8350209
AP8350209
Contact
2
PISTON
AP8350150
AP8350150
Contact
3
NUT
AP8350103
AP8350103
Contact
4
CYLINDER HEAD
AP8350186
AP8350186
Contact
5
GASKET
AP8350125
AP8350125
Contact
6
STUD BOLT
AP8350156
AP8350156
Contact
7
GASKET
AP8350126
AP8350126
Contact
8
GASKET
AP8350131
AP8350131
Contact
9
RING
AP8350177
AP8350177
Contact
10
RING
AP8350178
AP8350178
Contact
11
PISTON PIN D
AP8350180
AP8350180
Contact
12
RING
AP8350069
AP8350069
Contact
13
PISTON
AP8350151
AP8350151
Contact
14
PISTON
AP8350152
AP8350152
Contact
15
PISTON RING SET
AP8350172
AP8350172
Contact
16
PISTON RING SET
AP8350173
AP8350173
Contact
17
ENGINE CPL.
AP8350489
AP8350489
Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times. The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible. Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts. Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1. Find on this page all the original spare parts relating to the Head - Cylinder - Piston of your Aprilia Mini RX Entry of MINI-RX. Let us know if you have any questions.
