FRONT FORK M / N IM B FOR APRILIA AF1 FUTURA 1992

Front fork N IM A

Item numbers
Front fork M/N IM B Aprilia APRILIA-MOTORCYCLES 50 AF1 1992 AF1 FUTURA
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
25
26
1
FRONT FORK

AP8203389  

Contact
2
DUST COVER

AP8120211  

Unit Price Incl. Tax

3
DUST GUARD SUPPORT RING
SPACER

AP8101272  

Unit Price Incl. Tax

4
BALL BEARING

AP8110025  

Unit Price Incl. Tax

5
ROLLER BEARING

AP8110024  

Unit Price Incl. Tax

6
LOWER DUST COVER RING

AP8101271  

Unit Price Incl. Tax

7
SCREW

AP8203268  

Contact
8
WASHER

AP8152173  

Contact
9
SCREW
FORK SCREW M8X30

AP8203570  

600123

Unit Price Incl. Tax

10
SPRING

AP8203331  

Contact
11
SPACER

AP8203458  

Contact
12
PLUG
COVER

AP8203334  

Contact
14
WASHER

AP8203335  

Contact
15
FORK UPPER PLATE

AP8203439  

Contact
16
RING NUT

AP8103928  

Contact
17
GASKET RING
GASKET RING

AP8203464  

Contact
18
GASKET RING

AP8203338  

Contact
19
DUST COVER

AP8203459  

Contact
20
HEX SCREW

AP8103735  

Contact
21
SEAL WASHER

AP8103734  

Contact
22
SLEEVE

AP8203461  

Contact
23
LH SLEEVE

AP8203463  

Contact
24
HUB+RH FORK LEG
HUB+RH FORK LEG

AP8203462  

Contact
25
STEM BASE

AP8203343  

Contact
26
PLUNGER, COMPLETE

AP8203418  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Front fork M/N IM B of your Aprilia AF1 FUTURA of AF1. Let us know if you have any questions.
