SWING ARM FOR APRILIA RXV STREET LEGAL 2011

Controls

Item numbers

SWING ARM
SWING ARM

855550

Contact

ROLLER CAGE 22X29X30

AP9100202

Contact

GASKET RING 22X29X4

AP9100203

£3,14

Unit Price Incl. Tax

PISTON PIN L=47, 5

AP9100952

£55,70

Unit Price Incl. Tax

PISTON PIN L=47, 5

AP9100952

£55,70

Unit Price Incl. Tax

REAR SWING ARM PIN M14 L=244

AP9100123

£145,67

Unit Price Incl. Tax

DAX FLANGE NUT M14X1, 5

AP8152244

£3,47

Unit Price Incl. Tax

SLIDING BLOCK
CHAIN GUIDE PLATE

855552

Contact

CHAIN GUIDE PLATE

855553

Contact

CHAIN COVER

00H01508181

£31,10

Unit Price Incl. Tax

PLATE
FRONT PLATE

855579

£12,51

Unit Price Incl. Tax

CHAIN TENS.ADJUSTER SCREW

AP8152305

£12,69

Unit Price Incl. Tax

NUT M8 - UNI 5588
NUT M8

AP8150027

£1,21

Unit Price Incl. Tax

CHAIN TENSIONER SLIDING BLOCK
RH CHAIN GUIDE PLATE

855697

Contact

CHAIN GUIDE PLATE
LH CHAIN GUIDE PLATE

855565

£15,33

Unit Price Incl. Tax

PASSATUBO FRENO POST.
BRAKE HOSE CABLE GUIDE

AP9100565

£12,51

Unit Price Incl. Tax

SELF-TAPPING SCREW M5X12
SCREW M5X12

018623

Contact

CUP FOR SHOE

AP8234020

£2,07

Unit Price Incl. Tax

SCREW W/ FLANGE
SCREW

AP8152278

598839

£1,21

Unit Price Incl. Tax

SCREW W/ FLANGE M6X45
SCREW W/ FLANGE

AP8152284

£1,80

Unit Price Incl. Tax

BUSH

AP9100287

£3,74

Unit Price Incl. Tax

SELF-LOCKING NUT M6X1

AP9100434

£6,34

Unit Price Incl. Tax

REAR WHEEL SPINDLE
REAR WHEEL SPINDLE M25 L=266, 5

855562

Contact

WASHER 25, 2 X 36 X 1 INOX AISI 304
WASHER 25, 2X36X1

AP8152323

£8,18

Unit Price Incl. Tax

WHEEL SPINDLE NUT M25X1, 5

855722

£46,36

Unit Price Incl. Tax

PLATE
REAR PLATE

855580

£9,51

Unit Price Incl. Tax

WASHER 5, 3X20X1, 6
WASHER 5X20X1, 5

AP8150255

£0,94

Unit Price Incl. Tax

BUSH
BUSH D.10-H.3, 5

AP9100053

£1,67

Unit Price Incl. Tax

SCREW TBEI M6X10 Z.N. -10.9 UNI ISO 73
HEX SOCKET SCREW

AP8152226

£1,34

Unit Price Incl. Tax

WASHER
WASHER 6, 4X15X1

AP8152181

£0,23

Unit Price Incl. Tax

SCREW M6X12

AP9150394

£1,21

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Swing arm of your Aprilia RXV STREET LEGAL of RXV. Let us know if you have any questions.
