VARIATOR FOR APRILIA LEONARDO (ENGINE YAMAHA) 2001

Water pump

Item numbers
Variator Aprilia APRILIA-SCOOTER 250 LEONARDO 2001 Leonardo (engine Yamaha)
1
2
3
4
5
5
6
7
7
7
8
9
9
9
10
10
10
11
12
12
13
13
14
15
1
FIXED PULLEY

AP8122615  

Contact
2
V-BELT

AP8122639  

Contact
3
WASHER

AP8122649  

Contact
4
FLANGED NUT

AP8122529  

Contact
5
OIL SEAL

AP8122540  

Contact
6
PULLEY ASSY., DRIVING

AP8122587  

Contact
7
PIN ROLLER

AP8122652  

Contact
8
RAMP PLATE

AP8122431  

Contact
9
SLIDER

AP8122616  

Unit Price Incl. Tax

10
SPACER

AP8122617  

Contact
11
COVER

AP8122630  

Contact
12
SCREW

AP8122601  

Contact
13
WASHER

AP8122650  

Contact
14
O-RING

AP8122555  

Contact
15
SPACER

AP8122455  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Variator of your Aprilia Leonardo (engine Yamaha) of LEONARDO. Let us know if you have any questions.
