CRANKCASE COVER - CRANKCASE COOLING FOR APRILIA SR MAX 2013

Crankshaft

Item numbers
Crankcase cover - Crankcase cooling Aprilia APRILIA-SCOOTER 125 SR 2013 SR MAX
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
1
TRANSMISSION COVER WITH U.P.
TRANSMISSION COVER WITH I.P.

8772935  

8768835

Unit Price Incl. Tax

2
EXTERNAL RING
SNAP RING

006635  

Contact
3
RADIAL BEARING 15X35X11
BALL BEARING

478985  

4789853

Unit Price Incl. Tax

4
PIN D.9, 5 H=15
REFERENCE PLUG (D9.5, H=15)

239388  

B015956

Unit Price Incl. Tax

5
COOLING COVER

876075  

1A014715

Unit Price Incl. Tax

6
SCREW
SCREW M6X25

018553  

Contact
7
FILTERING ELEMENT

875701  

Unit Price Incl. Tax

8
SCREW W/ FLANGE M6X30
FLANGED HEXAGONAL HEAD SCREW (M6X30)

289731  

B016792

Unit Price Incl. Tax

9
HOSE CLAMP

844964  

Unit Price Incl. Tax

10
SOUNDPROOFING PROTECTION

876428  

Unit Price Incl. Tax

11
ELASTIC PLATE
SPRING PLATE

181351  

Unit Price Incl. Tax

12
SCREW W/ FLANGE M6X50
FLANGED HEXAGONAL SCREW M6X50

430207  

B016775

Unit Price Incl. Tax

13
BUSH
SPACER

431577  

Unit Price Incl. Tax

14
COVER WITH LOGOTYPE "GILERA"

CM159901  

Unit Price Incl. Tax

15
AIR FILTER PANEL
PROTECTION

652802  

Unit Price Incl. Tax

16
BUSH
KNURLED BUSHING

830056  

Unit Price Incl. Tax

17
HEXAGONAL FLANGED HEAD SCREW(M6X35)
SCREW M6X35

414838  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
