WATER COOLER FOR APRILIA LEONARDO ST 2004

Central body - Mats

Item numbers
Water cooler Aprilia APRILIA-SCOOTER 125 LEONARDO 2004 Leonardo ST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
16
17
17
18
19
20
21
1
WATER COOLER

AP8104093  

Contact
2
WATER COOLER UPPER SUPPORT

AP8134453  

Contact
3
WATER COOLER GASKET

AP8144078  

Contact
4
FAN UPPER SUPPORT

AP8134411  

Contact
5
FAN, CPL.

AP8124446  

Contact
6
SILENT-BLOCK
SILENT-BLOCK *

AP8120275  

Unit Price Incl. Tax

7
WATER COOLER LOWER SUPPORT

AP8134454  

Contact
8
FRONT SHIELD SUPPORT

AP8134320  

Contact
9
THERMAL SWITCH

AP8112677  

Contact
10
ALUMINIUM WASHER

AP8121837  

Unit Price Incl. Tax

11
SCREW
SCREW W/ FLANGE M6X20

AP8152279  

Unit Price Incl. Tax

12
EXPANSION TANK

AP8138946  

Unit Price Incl. Tax

13
RAD CAP W/ VENT

AP8201463  

Contact
14
BREATHER PIPE

AP8144056  

Contact
15
HOSE CLIP D12, 5X8
HOSE CLAMP 12, 5X8

AP8102239  

Unit Price Incl. Tax

16
SCREW
SCREW W/ FLANGE M5X15

AP8152273  

Unit Price Incl. Tax

17
CABLE-GUIDE

AP8221150  

Unit Price Incl. Tax

18
SELF-LOCKING NUT M5*
SELF-LOCKING NUT M5

AP8152306  

Contact
19
CLIP M5

AP8102375  

Unit Price Incl. Tax

20
SPRING PLATE M6
SPRING PLATE (M6)

AP8102376  

254485

Unit Price Incl. Tax

21
PIPE 5X9

AP8220402  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Water cooler of your Aprilia Leonardo ST of LEONARDO. Let us know if you have any questions.
