1
Engine displacement
125
2
Model
TUONO
3
Year
2004
4
Trim
RS 125 Tuono
5
Parts Catalog
Lights
6
Parts Diagram
Parts Catalog
Rear brake caliper
by
Electrical system I
Lights
1
2
3
4
5
6
6
7
7
8
9
10
11
12
13
14
15
15
15
15
16
17
18
18
18
18
19
20
21
22
1
Headlight
AP8124513
Not Available
1
Headlight
AP8124429
Not Available
2
Taillight
AP8124492
Not Available
3
Upper light guard decal
AP8147545
Not Available
4
Lower light guard decal
AP8147546
£16,64 Unit Price incl. VAT
5
Rear headlight supp.
AP8134446
Not Available
6
RH front/LH rear turn indic.
AP8127536
Not Available
7
LH front/RH rear turn indic.
AP8127535
Not Available
8
Screw 4,2x16*
AP8152351
£0,18 Unit Price incl. VAT
9
Spring
AP8124525
Not Available
10
Headlight wiring w/harness
AP8124634
Not Available
11
Taillight lens
AP8124527
Not Available
12
Taillight wiring harn.
AP8124489
Not Available
13
Rear reflector
AP8112916
£12,35 Unit Price incl. VAT
14
Nut M4
AP8150204
£1,88 Unit Price incl. VAT
15
Turn indicator lens
GU32753710
Not Available
16
Washer 4,3X9X0,8
AP8150158
£1,27 Unit Price incl. VAT
17
Screw 4,2x20*
AP8150270
£0,98 Unit Price incl. VAT
18
Lamp, orange
GU93450126
Not Available
19
Lamp P21/5W 12V
AP8224389
Not Available
20
Lamp H3 12V
AP8127230
Not Available
21
Lamp W3W 12V
AP8127164
Not Available
22
Extension
AP8127533
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
