1
Engine displacement
1000
2
Model
TUONO
3
Year
2004
4
Trim
RSV 1000 Tuono
5
Parts Catalog
R-RF version rear wheel
6
Parts Diagram
Parts Catalog
Air box
by
Saddle
R-RF version rear wheel
1
2
3
4
5
6
6
7
8
8
9
9
10
10
11
12
13
14
15
16
17
18
18
19
19
20
21
22
1
Chain cpl conn.link
AP8107148
Not Available
1
Chain cpl conn.link
AP8107118
Not Available
2
Chain ring Z=42
AP8107122
Not Available
3
Rear wheel, blue
AP8128044
Not Available
3
Rear wheel
AP8128037
Not Available
3
Rear wheel
AP8108977
Not Available
4
Connecting link
AP8107136
Not Available
4
Connecting link
AP8107150
Not Available
5
Tyre
0000000
Not Available
6
Flexible coupling rubber
AP8125731
Not Available
7
Tubeless tyre valve 90°
AP8104728
£18,78 Unit Price incl. VAT
7
Tubeless tyre valve
AP8104183
Not Available
8
Rear wheel spacer
AP8121225
£13,37 Unit Price incl. VAT
9
Spring drive fixing bush
AP8121408
Not Available
10
Low self-locking nut
AP8150436
£1,94 Unit Price incl. VAT
11
Crown holder cpl.
AP8125730
Not Available
11
Crown holder cpl.
AP8125900
Not Available
12
Rear wheel spindle
AP8125831
Not Available
13
Wheel spindle nut M25x1,5
AP8152324
£13,22 Unit Price incl. VAT
14
Washer 25,2x36x1
AP8152323
£8,57 Unit Price incl. VAT
15
Gasket ring 38x52x7
AP8125838
£2,71 Unit Price incl. VAT
16
Spacer
AP8125840
£67,03 Unit Price incl. VAT
17
Snap ring d52
AP8125839
£5,14 Unit Price incl. VAT
18
Spring drive spacer
AP8125732
£86,94 Unit Price incl. VAT
19
Bearing 6205-2rs1 25x52x15
AP8110093
£69,65 Unit Price incl. VAT
20
Bearing 30x55x13
AP8110081
£25,36 Unit Price incl. VAT
21
Gasket ring 38x55x7
AP8121213
£13,72 Unit Price incl. VAT
22
Inside circlip d55
AP8121212
£2,80 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
