1
Engine displacement
200
2
Model
SPORT-CITY
3
Year
2006
4
Trim
Sport City E2
5
Parts Catalog
Carburettor I
6
Parts Diagram
Parts Catalog
Central stand
by
Front caliper
Carburettor I
1
2
3
4
5
6
7
7
8
9
1
Screw w/ flange M6x25
AP8550173
Not Available
1
screw TEF
AP8575035
Not Available
2
Hose clamp
AP8570079
Not Available
3
Carburettor cpl.
AP8580262
Not Available
3
Carburettor cpl.
AP8580265
Not Available
4
Intake manifold
AP8580082
Not Available
5
Carburettor gasket set
AP8580012
Not Available
6
Carburettor flange
AP8144700
Not Available
7
Hose clamp 40-60 h9
AP8121639
Not Available
8
Clip M6
AP8102376
Not Available
9
Hose clip D8x5,5*
AP8101770
£12,56 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
