1
Engine displacement
125
2
Model
SPORT-CITY
3
Year
2006
4
Trim
Sport City E3
5
Parts Catalog
Cylinder
6
Parts Diagram
Parts Catalog
Rear caliper
by
Cylinder
1
2
3
3
4
5
6
7
8
1
Cylinder base gasket 0,4
AP8580149
Not Available
1
Cylinder base gasket 0,6
AP8580150
Not Available
1
Cylinder base gasket 0,8
AP8580151
Not Available
2
Piston pin
AP8580001
Not Available
2
Piston pin
AP8580177
Not Available
3
Snap ring
AP8580216
Not Available
4
Ring 72x1.5
830486
£42,68 Unit Price incl. VAT
4
Compression ring d.57x1
485779
£21,97 Unit Price incl. VAT
5
Oil scraper ring d.57x2,5
485914
£20,21 Unit Price incl. VAT
5
Scraper ring 72x2,5
486363
£31,91 Unit Price incl. VAT
6
Oil scraper ring d.57x1
486362
£39,46 Unit Price incl. VAT
6
Scraper ring 72x1
484908
£39,19 Unit Price incl. VAT
7
Cylinder with piston
AP8176280
Not Available
7
Cylinder with piston
AP8580272
Not Available
7
Cylinder with piston
843291
Not Available
8
Piston assy cat3
AP8176316
Not Available
8
Piston assy cat4
AP8176317
Not Available
8
Piston assy
AP8176314
Not Available
8
Piston assy cat4
8432900004
Not Available
8
Piston assy cat3
8432900003
Not Available
8
Piston assy cat2
8432900002
Not Available
8
Piston assy
8432900001
Not Available
8
Piston assy cat3
AP8176309
Not Available
8
Piston assy cat4
AP8176310
Not Available
8
Piston assy cat2
AP8176315
Not Available
8
Piston assy cat2
AP8176308
Not Available
8
Piston assy
AP8176307
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
