1
Engine displacement
50
2
Model
SONIC
3
Year
2004
4
Trim
Sonic H2O
5
Parts Catalog
Front wheel
6
Parts Diagram
Parts Catalog
Catalytic exhaust unit
by
Rear wheel
Front wheel
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
16
17
18
19
20
21
22
23
24
1
Tyre
0000000
Not Available
2
Tyre
0000000
Not Available
3
Front wheel, grey
AP8208547
Not Available
3
Front wheel, gold
AP8208716
Not Available
3
Front wheel, dark grey
AP8208717
Not Available
3
Front wheel, yellow
AP8208555
Not Available
3
Front wheel, blue
AP8208746
Not Available
4
Odometer gear
AP8202008
£25,34 Unit Price incl. VAT
5
Front wheel spindle
AP8225356
Not Available
6
Front wheel spacer
AP8225326
Not Available
7
Low self-locking nut M12x1,25
AP8150373
£4,96 Unit Price incl. VAT
8
Screw w/ flange M8x30
AP8152288
£2,20 Unit Price incl. VAT
9
Front brake disc
AP8213383
Not Available
10
Front wheel spacer
AP8225342
Not Available
11
Bearing
AP8225316
Not Available
12
Washer 12x24x3
AP8225237
Not Available
13
Front brake caliper D30
AP8213244
Not Available
13
Front brake caliper
AP8213611
Not Available
14
Front brake hose
AP8213286
Not Available
15
Oil pipe screw
AP8113003
£2,08 Unit Price incl. VAT
16
Washer 10x14x1,6*
AP8113004
£1,87 Unit Price incl. VAT
17
Cable-guide
AP8121856
£13,28 Unit Price incl. VAT
18
Screw w/ flange M8x30
AP8152288
£2,20 Unit Price incl. VAT
19
Pads pair
AP8213245
Not Available
19
Pads pair
AP8213590
Not Available
20
Bleed valve cap
AP8213575
£5,94 Unit Price incl. VAT
20
Bleed valve cap
AP8113005
£5,94 Unit Price incl. VAT
21
Air bleed valve
AP8213108
£28,56 Unit Price incl. VAT
21
Air bleed valve
AP8213589
£27,98 Unit Price incl. VAT
22
Pin+Brake spring
AP8213227
£38,36 Unit Price incl. VAT
22
Pin+Brake spring
AP8213591
£24,36 Unit Price incl. VAT
23
Brake caliper cover
AP8213592
£23,63 Unit Price incl. VAT
23
Brake caliper cover
AP8213224
Not Available
24
Brake caliper rev. kit
AP8213579
£72,55 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
