Crankcase
1
1
2
3
4
5
5
5
5
6
7
7
8
9
9
10
10
11
12
12
13
14
15
16
16
17
18
19
20
21
22
23
24
25
1
Crankcase assy
AP0295388
Not Available
1
Crankcase assy
AP0295385
Not Available
2
Pin 6x40
AP0229380
Not Available
3
pipe
AP0224260
Not Available
4
Roller cage 8x12x8
AP0232275
Not Available
5
Pin M8x12
AP0632010
Not Available
6
Brass union
AP0924150
Not Available
7
Bush
AP0247555
£52,01 Unit Price incl. VAT
8
Bearing 6302
AP0232291
Not Available
9
Bearing 6203
AP0932032
£39,02 Unit Price incl. VAT
10
Oil seal 28x38x7
AP0230425
Not Available
11
Oil seal 25x38x7
AP0930675
Not Available
12
Bearing 6205
AP0232765
Not Available
13
Stud bolt M8x57/20
AP0940786
Not Available
14
Gasket 6x10
AP0650130
Not Available
15
Gasket ring 6x10
AP0230415
Not Available
16
Hex socket screw M6x45
AP0241821
Not Available
17
Sensor
AP0640190
Not Available
18
Stud bolt M8x28x20
AP0241381
Not Available
19
Loctite (green) 648 5gr.
AP0899788
Not Available
20
Silastic 732 Rtv 100 gr.
AP0297386
Not Available
21
Cover
AP0227325
Not Available
22
Kikst. coupling stop
AP0228250
Not Available
23
Hex socket screw M6x30
AP0840880
£5,96 Unit Price incl. VAT
24
Loctite (violet) 221 10cc.
AP0899785
Not Available
25
Loctite (green) 648 5gr.
AP0899788
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
