1
Engine displacement
650
2
Model
PEGASO
3
Year
2001
4
Trim
Pegaso IE
5
Parts Catalog
Rear electrical system
6
Parts Diagram
Parts Catalog
Front electrical system
by
Police electrical system
Rear electrical system
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
1
CDI unit assy
AP8127211
Not Available
2
Hex socket screw M5x25
AP8152270
£1,88 Unit Price incl. VAT
3
Main wiring harness
AP8124940
Not Available
4
Self-locking nut M5
AP8152306
Not Available
5
Rubber fuse box
AP8120754
£10,61 Unit Price incl. VAT
6
Screw w/ flange M6x20
AP8152279
£1,87 Unit Price incl. VAT
7
Curved spring washer *
AP8150182
£2,48 Unit Price incl. VAT
8
Rubber fuse box
AP8112942
Not Available
9
Fuse 7,5A
AP8112244
Not Available
10
Fuse 15A
AP8112176
Not Available
11
Fuse 20A
AP8112506
Not Available
12
Injection relay
AP8124869
Not Available
13
Voltage regulator
AP8112941
£102,94 Unit Price incl. VAT
14
Microswitch
AP8112996
£78,91 Unit Price incl. VAT
15
Relay rubber
AP8220546
£3,74 Unit Price incl. VAT
16
Inclination sensor
AP8124266
Not Available
17
Rubber sensor support
AP8144046
Not Available
18
Taillight wiring harn.
AP8124217
Not Available
19
Lamp WY5W 12V
AP8224393
Not Available
20
Black cable guide
AP8201727
£1,14 Unit Price incl. VAT
21
Block 3 vie
AP8112254
Not Available
22
Rotary switch
AP8124977
Not Available
23
Oil-neutral gear harness
AP8112959
Not Available
24
Voltage regulator support
AP8146525
Not Available
25
Hex threaded insert
AP8102902
£1,88 Unit Price incl. VAT
26
Screw w/ flange M6x12
AP8152277
£1,88 Unit Price incl. VAT
27
Auxiliary wiring harness
GU80748010
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
