1
Engine displacement
600
2
Model
PEGASO
3
Year
1991
4
Trim
PEGASO
5
Parts Catalog
Oil pump
6
Parts Diagram
Parts Catalog
Crank-case
by
Timing system
Oil pump
1
2
2
3
4
5
6
7
8
9
11
11
11
11
11
12
12
12
12
12
12
12
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
31
32
33
34
35
35
36
37
38
38
39
40
40
41
42
43
45
45
47
48
48
49
49
50
50
50
50
50
50
50
1
Crankcase assy
AP0294081
Not Available
2
Locating dowel 9,8x10
AP0229140
Not Available
3
Pin
AP0229160
Not Available
4
Plug screw M10x10
AP0241905
Not Available
5
Oil seal
AP0850055
Not Available
6
Oil seal 25x40x7
AP0230395
Not Available
7
Bearing 205EC3
AP0232240
Not Available
8
Bearing 6303 ETN9
AP0932815
Not Available
9
Gasket
AP0250370
Not Available
11
Break washer a6
AP0945751
Not Available
12
Hex socket screw M6x60
AP0240371
Not Available
16
Joint
AP0256210
Not Available
17
Joint
AP0256220
Not Available
18
Bearing 6205
AP0232765
Not Available
19
Ball bearing
AP0932033
Not Available
20
Thrust washer sp.0,2 mm
AP0427420
Not Available
20
Thrust washer 0,1 mm
AP0427422
Not Available
20
Thrust washer 42x52x0,3
AP0427421
Not Available
21
Thrust washer 0,3 mm
AP0227521
Not Available
21
Thrust washer 0,1 mm
AP0227522
Not Available
21
Thrust washer 0,5 mm
AP0227520
Not Available
22
plate
AP0227115
Not Available
23
screw
AP0940315
Not Available
24
screw
AP0241777
Not Available
25
Oil strainer
AP0212595
Not Available
26
Oil strainer
AP0256160
Not Available
27
Gasket
AP0230840
Not Available
28
O-ring
AP0831762
Not Available
29
O-ring 13,3x2,4
AP0230880
Not Available
30
Hex socket screw M6x25
AP0840861
Not Available
31
Gasket
AP0250010
Not Available
32
Hex screw M12x12
AP0241401
Not Available
33
Magnetic drain plug M12x1,5
AP0241782
Not Available
34
Contact screw
AP0241850
Not Available
35
Pin
AP0229160
Not Available
36
Stud bolt M10x196
AP0240445
Not Available
37
Stud bolt
AP0240435
Not Available
38
Nut
AP0242851
Not Available
39
Cap nut
AP0242695
Not Available
40
Joint
AP0256250
Not Available
41
Gasket ring 8x13
AP0950141
Not Available
42
Hex socket screw
AP0841521
Not Available
43
Stud bolt
AP0940370
Not Available
45
Bush
AP0247320
Not Available
47
Loctite (orange) 574
AP0899784
Not Available
48
Loctite (green) 648 5gr.
AP0899788
Not Available
49
Molykote G-N 50gr.
AP0297433
Not Available
50
Loctite (violet) 221 10cc.
AP0899785
Not Available

Find the detailed Oil pump APRILIA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original APRILIA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
