1
Engine displacement
125
2
Model
PEGASO
3
Year
1993
4
Trim
PEGASO
5
Parts Catalog
Drive shaft
6
Parts Diagram
Parts Catalog
Frame
by
Special tools
Drive shaft
1
2
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
27
27
27
28
29
29
1
Crankshaft cpl.
AP0294770
Not Available
2
Bearing
AP0832590
Not Available
3
Spacer D50x62x0,3
AP0427591
Not Available
3
Spacer D50x62x0,1
AP0427590
Not Available
4
Break washer A12
AP0945754
Not Available
5
Nut M12x1
AP0642051
Not Available
6
O-ring 18x3,5
AP0430460
Not Available
7
Balance shaft gear Z=27
AP0234431
£72,84 Unit Price incl. VAT
8
Transmission key 3x3,7
AP0246055
Not Available
9
Primary transm.
AP0293926
Not Available
10
Washer
AP0945756
Not Available
11
Nut
AP0242570
Not Available
12
Free pinion shaft
AP0237905
Not Available
13
Thrust washer 10,1/17/1
AP0827590
Not Available
14
Intermediate gear
AP0634030
Not Available
15
Bearing 6302
AP0232291
Not Available
16
Balance shaft
AP0237949
Not Available
17
Ball bearing 6005
AP0232340
Not Available
18
Thrust washer
AP0227280
Not Available
19
screw
AP0940315
Not Available
20
Circlip AV 20
AP0245650
Not Available
20
Seeger 25x1,2
AP0945810
Not Available
21
Roller cage 15x19x20
AP0932028
£25,98 Unit Price incl. VAT
22
Piston assy 53,99
AP0295346
Not Available
22
Piston assy 54,00 mm
AP0294755
Not Available
22
Piston assy 53,98 mm
AP0294747
Not Available
23
Ring d54
AP0215670
Not Available
24
Piston pin
AP0216139
Not Available
25
Stop ring D15
AP0945635
Not Available
26
Connecting rod cpl.
AP0295374
Not Available
27
Loctite Anti Seize 50ml.15378
AP0297434
Not Available
28
Loctite (green) 648 5gr.
AP0988788
Not Available
29
Loctite (violet) 221 10cc.
AP0899785
Not Available

Find the detailed Drive shaft APRILIA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original APRILIA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
