1
Engine displacement
660
2
Model
TUAREG
3
Year
2023
4
Trim
Tuareg 660 Euro 5 ABS
5
Parts Catalog
Timing system
6
Parts Diagram
Parts Catalog
FLYWHEEL COVER
by
Timing system
14
13
12
11
10
8
7
6
16
15
9
5
4
3
3
2
1
1
Arbre à cames admission
1A0214275
£506,02 Unit Price incl. VAT
2
Arbre à cames d'échappement
1A0214295
£421,68 Unit Price incl. VAT
3
Couronne distribution
1A012867
£89,70 Unit Price incl. VAT
4
Patin fixe
1A013825
£15,89 Unit Price incl. VAT
5
Patin tendeur de chaîne mobile
1A015310
£18,23 Unit Price incl. VAT
6
Vis spéciale
1A018441
£7,60 Unit Price incl. VAT
7
Chaîne de distribution
1A012147
£81,32 Unit Price incl. VAT
8
Patin fixe
1A017120
£8,29 Unit Price incl. VAT
9
Plaque
1A017119
£8,94 Unit Price incl. VAT
10
Chain stretching drive
2A000111
£93,41 Unit Price incl. VAT
11
O-ring
857176
£2,12 Unit Price incl. VAT
12
Rondelle plate
1A020131
£3,07 Unit Price incl. VAT
13
Vis spéciale
1A015611
£7,09 Unit Price incl. VAT
14
Vis à tête bombée Torx
1A013092
£1,50 Unit Price incl. VAT
15
Flat washer
016661
Not Available
16
Oil unload plug
AP9150174
£7,85 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
