1
Engine displacement
900
2
Model
DORSODURO
3
Year
2020
4
Trim
Dorsoduro 900 Euro 4 ABS
5
Parts Catalog
FRAME
6
Parts Diagram
Parts Catalog
ABS BRAKE SYSTEM
by
STEERING
FRAME
1
2
3
3
4
5
6
7
8
9
9
10
10
11
11
11
11
11
11
11
12
12
12
13
14
15
15
15
15
15
16
17
18
19
20
20
21
22
23
24
24
25
26
27
27
28
29
30
31
32
32
33
33
34
35
35
36
36
37
38
38
39
39
40
40
41
41
42
43
44
1
Châssis, rouge
89886800XR8
£1 702,78 Unit Price incl. VAT
2
LH side panel, black
85153700XNB
£696,85 Unit Price incl. VAT
3
RH flank frame,black
85153600XNB
£696,85 Unit Price incl. VAT
4
Shock absorber plate
851541
£299,42 Unit Price incl. VAT
5
Support de selle v.Rouge
85495200XR8
£1 484,69 Unit Price incl. VAT
6
Clip M5
AP8102375
£2,20 Unit Price incl. VAT
7
Hose clamp
GU06609600
£2,39 Unit Price incl. VAT
8
Exhaust pipe support clamp
851789
£54,64 Unit Price incl. VAT
9
Screw
852165
£7,18 Unit Price incl. VAT
10
Bush
853037
£20,86 Unit Price incl. VAT
11
Nut M12
271740
£2,20 Unit Price incl. VAT
12
Spring plate M8
575268
£2,24 Unit Price incl. VAT
13
Stand end stop
AP8144277
£5,05 Unit Price incl. VAT
14
Stand end stop
AP8144030
£13,58 Unit Price incl. VAT
15
Spring plate M6
254485
£1,64 Unit Price incl. VAT
16
Hex socket screw M10x30
AP8150195
£1,88 Unit Price incl. VAT
17
Plate
860404
£10,31 Unit Price incl. VAT
18
Black chain guide roller
AP8161074
£13,28 Unit Price incl. VAT
19
Spacer
AP8161076
£5,14 Unit Price incl. VAT
20
Ball bearing 8x22x7
AP9100175
£11,84 Unit Price incl. VAT
21
Screw w/ flange
AP8152291
£1,94 Unit Price incl. VAT
22
Upper plate
890206
£69,95 Unit Price incl. VAT
23
M8x35 flanged hex head screw
2B004782
£6,64 Unit Price incl. VAT
24
Screw w/ flange M8x20
2B002416
£3,86 Unit Price incl. VAT
25
Washer
AP8150009
£1,26 Unit Price incl. VAT
26
Bush
AP8121332
£3,43 Unit Price incl. VAT
27
Spacer
853036
£3,83 Unit Price incl. VAT
28
Spacer
853035
£12,42 Unit Price incl. VAT
29
Hex socket screw M6x20
AP8150044
£1,27 Unit Price incl. VAT
30
T bush
AP8221023
£1,64 Unit Price incl. VAT
31
Rubber spacer
AP8120030
£1,38 Unit Price incl. VAT
32
Engine pin
851784
£25,76 Unit Price incl. VAT
33
Washer 13x24x2,5*
AP8150101
£1,21 Unit Price incl. VAT
34
Missing description
2B004168
£7,78 Unit Price incl. VAT
35
Hex socket screw M 8X35
2B002216
£0,61 Unit Price incl. VAT
36
Nut
272176
£0,98 Unit Price incl. VAT
37
Washer 8,5x15x0,8
AP8150376
£1,76 Unit Price incl. VAT
38
Washer 8,4x16x1,6
AP8150017
£1,88 Unit Price incl. VAT
39
Bush
860909
£10,03 Unit Price incl. VAT
40
Hex socket screw M8x55
AP8150046
£1,85 Unit Price incl. VAT
41
Washer
AP8150018
£1,88 Unit Price incl. VAT
42
Black hose 98x2*
AP8120422
£1,49 Unit Price incl. VAT
43
Hose clamp
AP8120657
£1,88 Unit Price incl. VAT
44
Hose clamp 155x2
AP8102386
£0,18 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
