1
Engine displacement
50
2
Model
SR
3
Year
2018
4
Trim
SR 50 R H2O 2T Euro 4
5
Parts Catalog
FRAME
6
Parts Diagram
Parts Catalog
FRONT LIGHTS
by
Carburettor
FRAME
1
2
2
3
4
5
6
7
8
9
10
11
1
Frame
1B004905
£800,21 Unit Price incl. VAT
2
Ball ring set, complete
AP8223060
Not Available
3
Support
AP8234233
£16,88 Unit Price incl. VAT
4
Cable-guide
AP8221310
£2,96 Unit Price incl. VAT
5
Clip M5
AP8102375
£2,20 Unit Price incl. VAT
6
Spring plate M6
254485
£1,64 Unit Price incl. VAT
7
Screw w/ flange
598839
£1,27 Unit Price incl. VAT
8
Black hose 178x4
AP8120416
£1,00 Unit Price incl. VAT
9
Hose clamp
AP8120657
£1,88 Unit Price incl. VAT
10
Lowe dust cover
AP8220710
£3,05 Unit Price incl. VAT
11
Die cut protection
AP8217040
£24,08 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
