1
Engine displacement
50
2
Model
SR
3
Year
2019
4
Trim
SR 50 R GP REPLICA H2O 2T Euro 4
5
Parts Catalog
CRANKCASES I
6
Parts Diagram
Parts Catalog
ENGINE - GEAR LEVER - SPROCKET
by
AIR BOX
CRANKCASES I
1
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
1
Complete crankcase
1A0098815
£475,79 Unit Price incl. VAT
2
Stud bolt
1A003633R
£3,49 Unit Price incl. VAT
3
Silent-block
266773
£10,69 Unit Price incl. VAT
4
Bush Ø8xØ12x8
431860
£1,43 Unit Price incl. VAT
5
Silent block
666991
£4,63 Unit Price incl. VAT
6
Ring
287223
£0,62 Unit Price incl. VAT
7
Nut
020006
Not Available
8
Ring
113533
£1,97 Unit Price incl. VAT
9
Nut M8
020008
Not Available
10
Gasket ring 8.16.10
479692
£7,64 Unit Price incl. VAT
11
Screw w/ flange
B017632
£2,48 Unit Price incl. VAT
12
Pin 6,5x9,5x15
239388
Not Available
13
Bearing 20x47x14
434735
£17,32 Unit Price incl. VAT
14
Circlip
006647
Not Available
15
Gasket ring
478498
£6,29 Unit Price incl. VAT

Find the detailed :label APRILIA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original APRILIA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
